Setting up the monitor │ 61
VESA wall mounting (optional)
(Screw dimension: M4 x 10 mm).
Refer to the instructions that come with the VESA-compatible wall mounting kit.
1. Pl
ace the monitor panel on a soft cloth or cushion on a stable flat table.
2. R
emove the stand (see Removing the monitor stand).
3. Use
a Phillips crosshead screwdriver to remove the four screws securing the
plastic cover.
4. A
ttach the mounting bracket from the wall mounting kit to the monitor.
5. Moun
t the monitor on the wall. For more information, see the documentation
that is shipped with the wall mounting kit.
NOTE: For use only with UL or CSA or GS-listed wall mount bracket
with minimum weight or load bearing capacity of 31.12 kg.
