About this task
Steps
1. Pry open the display bezel from the inner edge at the left and right sides of the display assembly.
2. Pry open the display bezel from the inner edge at the top side of the display assembly.
3. Pry open the hinge caps at the bottom side of the display assembly.
4. Pry open the display bezel from the inner edge at the bottom side of the display assembly.
5. Lift and remove the display bezel from the display assembly
NOTE:
CAUTION: DO NOT use a scribe or any other objects to pry up the display bezel in the manners shown in the
images below as the pressure applied on the display panel by the scribe will damage the display panel.
48 Disassembly and reassembly
