Dell Vostro 3750 - 23 LED Board; Removing the LED Board

23
LED Board
Removing The LED Board
1. Follow the procedures in Before Working On Your Computer .
2. Remove the battery .
3. Remove the keyboard .
4. Remove the memory door .
5. Remove the optical drive .
6. Remove the palm rest .
7. Release the latch on system board connector and then disconnect the LED
cable.
8. Remove the LED board from the chassis.
91
