System Board
Removing The System Board
1. Follow the procedures in Before Working On Your Computer .
2. Remove the battery .
3. Remove the media dummy card .
4. Remove the ExpressCard .
5. Remove the keyboard .
6. Remove the memory door .
7. Remove the optical drive .
8. Remove the palm rest .
9. Remove the hinge cover .
10. Remove the WLAN card .
11. Remove the display assembly .
12. Remove the system fan .
13. Remove the ExpressCard cable
14. Disconnect the DC-in cable from the system board.
