Thermal Fan
Removing The Thermal Fan
1. Follow the procedures in Before Working On Your Computer.
2. Remove the Secure Digital (SD) card.
3. Remove the base cover.
4. Remove the battery.
5. Remove the audio board and the hard drive.
6. Remove the wireless local area network (WLAN) card.
7. Remove the wireless wide area network (WWAN) card.
8. Remove the LED cover.
9. Remove the memory.
10. Remove the keyboard.
11. Remove the card reader board.
12. Remove the coin cell battery.
13. Remove the system board .
14. Remove the screw that secures the thermal fan to the computer.
15. Lift the fan up and away from the computer.
NOTE: To install the thermal fan, see Installing The Thermal Fan.
