Battery
Removing The Battery
1. Follow the procedures in Before Working On Your Computer.
2. Remove the Secure Digital (SD) card.
3. Remove the base cover.
4. Lift the black cable-release clip to release the battery cable from the connector on the system board and
disconnect the battery cable.
5. Remove the screws that secure the battery to the computer.
6. Lift the battery up and away from the computer.
NOTE: To replace the battery, see Installing The Battery.
