Memory
Removing The Memory
1. Follow the procedures in Before Working On Your Computer
2. Remove the LED cover.
3. Use your fingertips to spread apart the securing clips on each end of the memory module connector until the
memory module pops up.
4. Remove the memory module from its connector on the system board by drawing the module from the system board
at 45-degree angle.
NOTE: To replace the memory, see Installing The Memory.
Installing The Memory
NOTE: To remove or locate the memory, see Removing the Memory.
1. Push the memory module into the memory slot.
2. Press the clips to secure the memory module to the system board.
3. Install the LED cover.
4. Follow the procedures in After Working Inside Your Computer.
