Dell Vostro V130 - Wireless Wide Area Network (WWAN) Card; Removing The Wireless Wide Area Network (WWAN) Card

Wireless Wide Area Network (WWAN) Card
Removing The Wireless Wide Area Network (WWAN) Card
1. Follow the procedures in Before Working On Your Computer.
2. Remove the Secure Digital (SD) Card.
3. Remove the base cover.
4. Remove the battery.
5. Disconnect the antenna cables from the WWAN card.
6. Remove the screw that secures the WWAN card to the computer.
7. Slide the WWAN card from its connector and remove it from the computer.
NOTE: To replace the WWAN card, see Installing The Wireless Wide Area Network (WWAN) Card.
