Replacing the control-buttons
board
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your
computer, follow the instructions in After working inside your
computer. For more safety best practices, see the Regulatory
Compliance home page at www.dell.com/regulatory_compliance.
Procedure
1 Slide the control-buttons board cable into the connector on the control-
buttons board and close the latch to secure the cable.
2 Slide the control-buttons board into the slot on the display bezel till the
securing clips lock in place.
Post-requisites
1 Replace the back cover.
2 Follow the procedure in step 4 in “Replacing the optical drive”.
3 Replace the stand.
42
