Removing the camera
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your
computer, follow the instructions in After working inside your
computer. For more safety best practices, see the Regulatory
Compliance home page at
www.dell.com/regulatory_compliance.
Prerequisites
NOTE: This chapter is applicable only for systems with a touch screen
display. For systems with a non-touch screen display, the microphones
will be integrated on the camera assembly.
1 Remove the stand.
2 Follow the procedure from step 1 to step 2 in “Removing the optical
drive”.
3 Remove the back cover.
4 Remove the system-board shield.
Procedure
1 Disconnect the microphone and camera cable from the system board.
2 Note the routing of the camera cable and remove it from the routing
guides and tab on the display-assembly base.
3 Note the routing of the antenna cable and remove it from the tab on the
display-assembly base.
49
