Dell W15B - Removing the Display Cable; Prerequisites; Procedure

Removing the display cable
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your
computer, follow the instructions in After working inside your
computer. For more safety best practices, see the Regulatory
Compliance home page at
www.dell.com/regulatory_compliance.
Prerequisites
1 Remove the stand.
2 Follow the procedure from step 1 to step 2 in “Removing the optical
drive”.
3 Remove the back cover.
4 Remove the memory module.
5 Remove the wireless card.
6 Remove the control-buttons board.
7 Remove the microphone.
8 Remove the system-board shield.
9 Remove the heat sink.
10 Remove the system board.
Procedure
1 Peel off the tape that secures the display cable to the display assembly.
2 Press the clips and disconnect the display cable from the display
assembly.
69
