Clearing CMOS Settings
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your
computer, follow the instructions in After working inside your
computer. For more safety best practices, see the Regulatory
Compliance home page at
www.dell.com/regulatory_compliance.
Prerequisites
1 Remove the stand.
2 Follow the procedure from step 1 to step 2 in “Removing the optical
drive”.
3 Remove the back cover.
4 Remove the system-board shield.
Procedure
1 Locate the CMOS jumper (CMCL R2) on the system board.
NOTE: For more information on the location of the jumper, see
“System-board components”.
2 Remove the jumper plug from the password jumper-pins (PSWD) and
connect it to the CMOS jumper-pins.
