Display panel
Removing the display panel
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the back cover.
3. Remove the bottom cover.
4. Remove the stand.
5. Remove the hard drive.
6. Remove the system-board shield.
7. Remove the system board.
About this task
The following image indicates the location of display panel and provides a visual representation of the removal procedure.
Removing and installing components 55
