Removing and installing components
NOTE: The images in this document may differ from your computer depending on the configuration you ordered.
Inside view of your computer
NOTE: The appearance of heat sink differs depending on the graphics configuration you ordered.
1. heat sink
2. fan
3. CMOS clear jumper
4. password clear jumper
5. speakers (2)
6. media-card reader
7. wireless-card shield
8. microphones (2)
9. solid-state drive
10. system board
11. hard drive
12. display-assembly base
13. base panel
14. memory modules
15. retractable-camera assembly
16. coin-cell battery
Recommended tools
The procedures in this document may require the following tools:
2
Removing and installing components 9
