Trigno™ Wireless Biofeedback System
- 15 -
Getting Started with the Trigno System
Powering the Base Station
Trigno Systems are equipped with a universal medical power supply and are
provided with interchangeable country-specific plug adapters. Connect the
Trigno power supply to the circular DC jack located on the side of the Base
Station. Energize the power supply by connecting it to a Mains outlet or to an
isolation transformer. The power LED on the Base Station will illuminate
anytime power is applied.
Trigno System are specifically designed and approved to
function only with the Power Supply provided. Power Supply
substitutions constitute a violation of the medical safety
approvals and will void the warranty.
Figure 2: Connecting the SC-P05 power supply to the Base Station.
Charging the Sensors
All sensors are fitted with a sealed lithium polymer cell and are charged with
the provided base station powered from a universal medical grade power
supply. A full charge will generally require 3 hours or less to complete,
depending on the battery age, usage history and particular charge conditions.
The sensor arrow will glow amber during charging and illuminate green upon
charge completion. It is recommended to keep sensors docked and charging
even when not in use to maximize battery life, as sensor batteries will self-
discharge with time and will degrade if left uncharged for extended periods of
time.
