Configuring the Trigno Sensors
Once paired to the system, EMG data and IMU data from sensor can be
configured in the following ways:
Electromyographic (EMG) Sensing Ranges
Input Range
11 mV
Bandwidth
20-450 Hz
Inertial Measurement Unit (IMU) Ranges
Accelerometer*
±2 g
or
±4 g
or
±8 g
or
±16 g
Accelerometer Bandwidth*
24Hz - 470 Hz
Gyroscope*
±250 dps
or
±500 dps
or
±1000 dps
or
±2000 dps
Gyroscope Bandwidth*
24 Hz - 360 Hz
*Note that accelerometer and gyroscope range settings and bandwidth settings are
configured by the software. Typical bandwidths are set to 50 Hz.
**Note that the magnetometer has a fixed range and a fixed bandwidth.
