Delsys TRIGNO - Reference Specifications

Trigno™ Wireless Biofeedback System
- 29 -
Reference Specifications
RF Frequency Band
2400-2483 MHz (ISM band)
Sensor Dimension
27 x 37 x 13 mm (excluding leads)
Mass
14 g
Temperature Range
(1)
5 - 45 degrees Celsius
Transmission Range
40 meters
(2)
EMG Signal Input Range
11mV r.t.i.
EMG Signal Bandwidth
20-450 Hz
EMG Contact Dimensions
0.5 mm
Contact Material
(3)
99.99% silver
Accelerometer Range
±2g, ±4g, ±8g, ±16g
Accelerometer Bandwidth
24 Hz – 470Hz (configurable in software)
Gyroscope Range
±250 dps, ±500 dps. ±1000dps, ±2000dps
Gyroscope Bandwidth
24Hz – 360 Hz (configurable in software)
Inter-Sensor Delay
< 1 sample period (Base Station only)
Intra-Channel Delay
< 1-2 sample period
Analog Output Range
± 5 V (Base Station only)
Analog Output Bandwidth (Ch. 1-16)
DC-500 Hz (Base Station Only
Analog Output Bandwidth (Ch. 17-64)
DC-50 Hz (Base Station Only)
Analog Output Group Delay (Ch. 1-16)
48 ms (Base Station Only)
Analog Output Group Delay (Ch. 17-64)
96 ms (Base Station Only)
Software Compatibility
EMGworks, Galileo Analytics, API
Battery Life
2 – 3 hours
3
rd
-party Integration Support
Analog outputs, Digital SDK/API support
1) Exposure beyond these temperature limits may damage the rechargeable battery.
2) Transmission range determined as maximum distance between two supported recording locations.
3) Sensor skin contacts are made from pure silver and should not be used if allergic reactions to silver are expected or found to occur.
