Delta Electronics RT Series User Manual

Chapter 2 Introduction
25
No. Item Functions
1
Input
Breaker
Protects the utility power from further damage when the UPS
fails. Please see ,QSXW%UHDNHU for detailed information.
2
Fan Cools and ventilates the UPS.
3
Smart Slot
Accepts SNMP, Relay I/O or ModBus card (optional). Please
see &KDSWHU&RPPXQLFDWLRQ,QWHUIDFHV for detailed
information.
4
Output
Receptacles
B/RDG
Connect to your loads.
5
Output
Receptacles
B/RDG
Connect to your load.
6
External
Battery Pack
Connector
Connects to the Delta external battery pack (optional).
Please see 'HOWD([WHUQDO%DWWHU\3DFN2SWLRQDO
&RQQHFWLRQ for detailed information.
(1 kVA: 24V DC 40A)
(2 kVA: 48V DC 40A)
(3 kVA: 72V DC 40A)
7
AC Input
Socket
Connects the UPS to the mains.
8
Ground
Terminal
For UPS grounding
9
REPO Port
Shuts down the UPS completely. Please see &KDSWHU
&RPPXQLFDWLRQ,QWHUIDFHV for detailed information.
10
RS-232 Port
Communication interface port. Please see &KDSWHU
&RPPXQLFDWLRQ,QWHUIDFHV for detailed information.
11
USB Port
Communication interface port. Please see &KDSWHU
&RPPXQLFDWLRQ,QWHUIDFHV for detailed information.
12
Output
Receptacle
Connects to your load.
