Delta-q IC650 Troubleshoot Manual

IC Series Charger Interface
16
IC Series Charger Interface
16
The E and F codes are followed by three
numbers and a period to indicate different
conditions (e.g., E-0-0-4.). See Charger
Fault Codes or Charger Error Codes for
details on these conditions and their
solutions.
USB CODE
meaning the USB interface is active,
and the USB flash drive should not be
removed.
E CODES
mean an external error condition that
may cause the charging to stop.
P CODES
indicate the charge profile number.
F CODES
mean an internal fault condition has
caused charging to stop.

Delta-q IC650 Specifications

General

Input Voltage	85-265 VAC
Input Frequency	45-65 Hz
Output Power	650 W
Efficiency	93%
Storage Temperature	-40°C to +85°C
Protection	Over-voltage, Over-temperature, Short-circuit
Communication	CAN bus
Cooling Method	Convection
Output Voltage	12-48 VDC
