Delta-q IC650 Troubleshoot Manual

ELECTRICAL INSTALATION
26
CABLE DRESSING
It is recommended that AC, DC, and signal
cables be secured, especially in applications
where there are high vibration and shock
loads. Cables and cords used to secure
cables should be rated to at least 105°C
(221°F). Delta-Q Technologies offers cable
clamps and sealed, locking AC cables to
provide improved system robustness.
The IC650 charger provides a channel
between the heat sink fins to thread the DC
Cabling through the front side of the charger
and clamp the cable in place.

Delta-q IC650 Specifications

General

Input Voltage	85-265 VAC
Input Frequency	45-65 Hz
Output Power	650 W
Efficiency	93%
Storage Temperature	-40°C to +85°C
Protection	Over-voltage, Over-temperature, Short-circuit
Communication	CAN bus
Cooling Method	Convection
Output Voltage	12-48 VDC
