Delta-q IC650 Troubleshoot Manual

IC Series Charger Interface
15
IC Series Charger Interface
15
NOTES
The Charging Output Indicator is
solid yellow when the charger output
is active. Take appropriate actions
while handling the charger, as there
is a risk of electric shock.
The USB Host Port provides read
and write USB functionality. Using
a standard USB flash drive, a user
can download charge tracking data,
and update the charger’s software
and charging profiles.
The Charge Profile/Error Display
shows one of four possible codes to
indicate different conditions:

Delta-q IC650 Specifications

General

Input Voltage	85-265 VAC
Input Frequency	45-65 Hz
Output Power	650 W
Efficiency	93%
Storage Temperature	-40°C to +85°C
Protection	Over-voltage, Over-temperature, Short-circuit
Communication	CAN bus
Cooling Method	Convection
Output Voltage	12-48 VDC
