IC900 & IC1200 DC Wiring Instructions
41
To attach DC cabling to the IC900 and IC1200
chargers, you need the following items:
• 1 Torx T30 screwdriver
• 1 Torx T10 screwdriver
• 2 Torx T30/M6 screws (provided)
• 2 longer Torx T10 screws (provided)
• 1 shorter Torx T10 screw (provided)
•
1 DC cable with ring terminals for
attachment into the DC block
• 1 DC block cover (provided)
• 1 DC cable clamp (provided)
1. Remove the DC terminal block cover by
lifting it vertically off the charger. Remove
the bag of parts that contains the cable
clamp, 2 longer Torx T10 screws, and 2
shorter Torx T10 screws.

Delta-q IC650 Specifications

General

Input Voltage	85-265 VAC
Input Frequency	45-65 Hz
Output Power	650 W
Efficiency	93%
Storage Temperature	-40°C to +85°C
Protection	Over-voltage, Over-temperature, Short-circuit
Communication	CAN bus
Cooling Method	Convection
Output Voltage	12-48 VDC
