IC900 & IC1200 DC Wiring Instructions
42
2.
Remove the positive and negative battery
fasteners (M6 screws). Attach the ring
terminals of the wires to the terminals
of the charger and secure with the T30/
M6 screws to a recommended torque of
4.5Nm +/-5%.
3. Secure the DC wire(s) in place using the
supplied cable clamp. Fasten with the two
longer Torx T10 screws to a recommended
torque of 0.6Nm +/-6%.
