Delta-q IC650 Troubleshoot Manual

4
GETTING STARTED ...........................6
High Voltage Safety ......................... 7
Electrical Safety Information .......... 8
Battery Safety Information ............. 9
Precautions ..................................... 10
IC SERIES CHARGER INTERFACE ......11
NOTES ............................................. 15
Normal Operation ........................... 17
Bulk Charging,
<80% Complete ...........................17
Absorption/Finish Phase,
>80% Complete ...........................18
Charging Complete ...................... 19
Configuring the IC650
Charger Using a USB Flash Drive ... 20
ELECTRICAL INSTALATION ..............22
General Considerations
for Machine Wiring .......................... 24
TABLE OF CONTENTS

Delta-q IC650 Specifications

General

Input Voltage	85-265 VAC
Input Frequency	45-65 Hz
Output Power	650 W
Efficiency	93%
Storage Temperature	-40°C to +85°C
Protection	Over-voltage, Over-temperature, Short-circuit
Communication	CAN bus
Cooling Method	Convection
Output Voltage	12-48 VDC
