Delta-q IC650 Troubleshoot Manual

5
Cable Dressing ................................ 26
IC650 DC OUTPUT .............................28
IC900/1200 DC OUTPUT ....................31
IC650 DC WIRING INSTRUCTIONS ..... 35
IC900 & IC1200 DC
WIRING INSTRUCTIONS ...................40
SIGNALS & CONTROL CONNECTOR ...44
TROUBLESHOOTING ......................... 48
Fault Codes - Internal
Condition Preventing Charging ....... 52
Error Codes - External Conditions .. 53
10 Most Common Error Codes ........ 54
Software / Algorithm errors ........... 56
Configuration Errors ....................... 57

Delta-q IC650 Specifications

General

Input Voltage	85-265 VAC
Input Frequency	45-65 Hz
Output Power	650 W
Efficiency	93%
Storage Temperature	-40°C to +85°C
Protection	Over-voltage, Over-temperature, Short-circuit
Communication	CAN bus
Cooling Method	Convection
Output Voltage	12-48 VDC
