iC900/1200 DC Output
34
PIN NOTES
B-
Each accepts a 1/4” or larger ring terminal
Fastener: Torx T30 screw, M6 nut.
Recommended Torque: 4.5Nm +/-5%
B+
L1
Each is a 1/4” quick-connect terminal.
L2
C1
Each is a 1/4” quick-connect terminal.
C2
C3
1/4” quick-connect terminal; normally closed to
battery positive.
Open when the charger output is active. 1.5A
max.
F+
1/4” quick-connect terminals
F-
Table 2-2
