IC650 DC Output
30
PIN
RECOMMENDED
WIRE SIZE
AWG/MM2
DESCRIPTION
B- 12/4.0 Battery negative
B+ 12/4.0 Battery positive
C1 20/0.5
Battery temperature
sense negative
C2 20/0.5
Battery temperature
sense positive
C3 20/0.5 Interlock Signal
PIN NOTES
B-
Each accepts a 1/4” or larger ring terminal
Fastener: Torx T30 screw, M6 nut.
Recommended Torque: 4.5Nm +/-5%
B+
C1
Each is a 1/4” quick-connect terminal.
C2
C3
1/4” quick-connect terminal; normally closed
to battery positive. Open when the charger
output is active. 1.5A max.
Table 1-1
Table 1-2
