Delta-q IC650 - IC900;1200 DC Output Connections & Specs

iC900/1200 DC Output
32
L2
L1
B-
C3
F+
C1
C2
F-
B+
Warning: Be careful not to allow battery
voltage to be applied to the blade terminals
(L1, L2, C1, C2, C3, F+, F-), as it will result
in permanent damage to the charger.
