Delta-q IC650 Troubleshoot Manual

Signals & Control Connector
47
WIRE COLOR DETAILS
WHITE / BLACK
Isolated reference ground for
CAN signals.
BLUE
Dry Contact Interlock relay:
Normally closed contact.
PURPLE
Dry Contact Interlock relay:
Common contact.
PINK
Dry Contact Interlock relay:
Normally open contact.
WHITE / RED
ORANGE Isolated CAN high signal.
BLACK
Do not connect to Battery
Negative. Can be used with Pin
9.
BROWN
YELLOW
IC650: Pin is unused
IC900/IC1200: Accessory Power
Output (+5VDC, 250 mA max)
WHITE / ORANGE Isolated CAN Low.
GREY
GREEN
For Remote LED. Pin 12 goes
high with respect to Pin 13 to
light the Remote LED green, and
vice versa to light the Remote
LED red.
RED
WHITE
Table 3-2

Delta-q IC650 Specifications

General

Input Voltage	85-265 VAC
Input Frequency	45-65 Hz
Output Power	650 W
Efficiency	93%
Storage Temperature	-40°C to +85°C
Protection	Over-voltage, Over-temperature, Short-circuit
Communication	CAN bus
Cooling Method	Convection
Output Voltage	12-48 VDC
