CUTTING
CROWN MOULDING
One of the many features of your saw is the ease of cut-
ting crown moulding. The following is an example of cut-
ting both inside and outside corners on 52/38 degree
wall angle crown moulding. NOTE: When cutting 45
degree wall angle crown moulding the following proce-
dure for inside and outside corners is the same with the
exception that the bevel position will always be at 30
degrees and the miter position will be 35-1/4 degrees to
the right or left.
1. Move the table to the 31-5/8 degree right miter posi-
tion and lock the table in position. NOTE: A triangle indi-
cator is provided on the miter scale to find this angle
quickly.
2. Tilt the saw blade to the 33-7/8 degree left bevel posi-
tion and tighten bevel lock handle. NOTE: A triangle
indicator is provided on the bevel scale to find this angle
quickly.
3. Place the crown moulding on the table with the
CEILING EDGE of the moulding against the fence, and
make the cut, as shown in Fig. 37. NOTE: The piece of
crown moulding used for the outside corner will always
be on the right hand side of the blade, as shown at (A)
Fig. 37. The piece of crown moulding used for the inside
corner will always be on the left hand side of the blade,
as shown at (B) Fig. 37.
4. To make the matching halves of the inside and outside
corners simply rotate the table to the 31-5/8 degree left
miter position and tighten table lock handle. NOTE: A tri-
angle indicator is provided on the miter scale to find this
angle quickly.
5. Place the crown moulding on the table with the WALL
EDGE of the crown moulding against the fence as
shown in Fig. 38, then make the cut. Again, the piece of
crown moulding used for the outside corner will always
be on the right side of the blade, as shown at (C) Fig. 38.
The piece of crown moulding used for the inside corner
will always be on the left side of the blade, as shown at
(D) Fig. 38.
6. Fig. 39, illustrates the two outside corner pieces;
(A) being the piece cut at (A) Fig. 37, and (C) being the
piece cut at (C) Fig. 38.
7. Fig. 40, illustrates the two inside corner pieces;
(B) being the piece cut at (B) Fig. 37, and (D) being the
piece cut at (D) Fig. 38.
