Delta AS16AP11P-A User Manual

AS Series Operation Manual
2-77
_2
 AS-F232/AS-FCOPM
AS-F232 AS-FCOPM
37
23.9
59.3
66.3
1
5
6 9
61.3
37
59.3
23.9
1
2
3
4
5
6
7
8
1
8
Unit: mm
Pin no. AS-F232 AS-FCOPM
1 - CAN_H
2 TX CAN_L
3
RX
GND
4
-
-
5
GND
-
6-9
-
-
 AS-FEN02
1
88
42
61.5
25.2
2
3
4
5
6
Number
Name
Description
1 MS indicator
Indicates if the module has been set
ON: the setting is complete
Blinking: the setting is not complete
OFF: no power
2 NS indicator
Indicates the status of Ethernet connection
Green lignt ON: a CIP connection is established
Green lignt BLINKING: a CIP connection is not established
Red light ON: duplicated IP address
Red light BLINKING: communication timeout / DLR conection
lost / IP address change
OFF: no power / network cable is not connected

Delta AS16AP11P-A Specifications

General

Brand	Delta
Model	AS16AP11P-A
Category	Control Unit
Language	English
