Delta AS16AP11P-A User Manual

Chapter 9 Ethernet Specification and Operation
9-73
9_
 H’87：Configuration 8
 H’C：Listen-Only Connection Number
 When Instance = 0, the Class Attributes are listed below.
Class
Attribute
Name
Access
Rule
Data Type Values Description
H’01 Revision Get UINT H’2 Revision of this object
H’02 Max Instance Get UINT H’C7
The maximum number of
instances
 When Instance = 64–87, the Instance Attributes are listed below. (Length of input and output is editable. The
maximum length is 250 words; supports only even bytes)
I/O Message Connection
Connection No. Function Instance Attribute Length
Connection 1
Input (TO)
0x65
D1000~D1099
Output (OT)
0x64
D0~D99
Configuration
0x80
Refer to the table below
Connection 2
Input (TO)
0x67
D1100~D1199
Output (OT)
0x66
D100~D199
Configuration
0x81
Refer to the table below
Connection 3
Input (TO)
0x69
D1200~D1299
Output (OT)
0x68
D200~D299
Configuration
0x82
Refer to the table below
Connection 4
Input (TO)
0x6B
D1300~D1399
Output (OT)
0x6A
D300~D399
Configuration
0x83
Refer to the table below
Connection 5
Input (TO)
0x6D
D1400~D1499
Output (OT)
0x6C
D400~D499
Configuration
0x84
Refer to the table below
Connection 6
Input (TO)
0x6F
D1500~D1599
Output (OT)
0x6E
D500~D599
