AS Series Operation Manual
9-74
_9
Configuration
0x85
Refer to the table below
Connection 7
Input (TO)
0x71
D1600~D1699
Output (OT)
0x70
D600~D699
Configuration
0x86
Refer to the table below
Connection 8
Input (TO)
0x73
D1700~D1799
Output (OT)
0x72
D700~D799
Configuration
0x87
Refer to the table below
 Instance Attribute
Instance
Attribute
Name
Access
Rule
Data Type Values Description
H’03 Data Set UINT H’0
The maximum number of
connections
H’04 Size Get UINT H’0
The number of connected
connections
* For connection input data, WRITE function is not supported.
* When IO connection is established, and the status of CPU module is RUN, WRITE function cannot be executed.
Configure the contents of input and output to edit the mapping address.
Configuration
Address
Data Type Contents
Defaults
(Connection 1)
Word[0] UINT
Input corresponding element
0: D, 1:X, 2: Y
0
Word[1] UINT Reserved 200
Word[2-3] DWORD Input corresponding element number 1000
Word[4] UINT
Output corresponding element
0: D, 2: Y
0
Word[5] UINT Reserved 200
Word[6-7] DWORD Output corresponding element number 0
