Chapter 9 Ethernet Specification and Operation
9-75
Examples of objects to be read and written
(1) Read data from connection 1 input:
Service code: H’0E
Class ID: H’04
Instance ID: H’65
Attribute ID: H’03
(2) Read data length of connection 2 output:
Service code: H’0E
Class ID: H’04
Instance ID: H’66
Attribute ID: H’04
(3) Read data from connection 2 output:
Service code: H’10
Class ID: H’04
Instance ID: H’66
Attribute ID: H’03
Data byte [0 ~ 200]: 00112233
(The range of data length is determined by configurations; default: 100 words)
