Delta AS16AP11P-A User Manual

AS Series Operation Manual
2-11
_2
7
6
113
87
55.3
1
3
4
5
2
 MIL connector, extension cable, and wiring modules (for AS332T-A/AS332P-A/AS324MT-A)
1. Extension Cable UC-ET010-24D (1M) / UC-ET020-24D (2M) / UC-ET030-24D (3M)
Length
3 9 40
1 2
500 +10m m
-
39 40
21 22
19 20
1 2
OUT
#1
IN
#2
1
2
2
Unit: mm
Number
Name
Description
1 IDC 40-pin terminal
Connects a digital input/output module and an external terminal
module.
2 IDC 20-pin terminal
Connects the external terminal modules UB-10-ID16A/UB-10-
OR16A/UB-10-OR16B
2. AS332T-A/AS332P-A/AS324MT-A and the external terminal module UB-10-ID16A
67.0
87.0
53.6
2
1
3
4
Unit: mm
Number
Name
Description
1
20-pin MIL connector
Connects the external terminal module and a wiring module
2
Terminals
Input/Output terminals for wiring
3 Clip
Hangs the external terminal module on a DIN rail
4 Set screw
Fixes the base
3. AS332T-A and the external terminal module UB-10-OR16A/AS332P-A, and UB-10-OR16B
Unit: mm
