ASCII Mode:
Command message (Master): Response message (Slave):
Start ‘:’ Start ‘:’
Slave Address
‘0’
Slave Address
‘0’
‘1’ ‘1’
Function
‘1’
Function
‘1’
‘0’ ‘0’
Starting data
address
‘0’
Starting data
address
‘0’
‘1’ ‘1'
‘1’ ‘1’
‘2’ ‘2’
Number of data
(In Word)
‘0’
Content of data
‘0’
‘0’ ‘0’
‘0’ ‘0’
‘2’ ‘2’
Number of data
(In Byte)
‘0’
LRC Check
‘D’
‘4’ ‘A’
Content of 1st
data
‘0’ End 1 (0DH)(CR)
‘B’ End 0 (0AH)(LF)
‘B’
‘8’
Content of 2nd
data
‘0’
‘0’
‘0’
‘0’
LRC Check
‘1’
‘3’
End 1 (0DH)(CR)
End 0 (0AH)(LF)
