Appendix A Accessories ASDA-B2
A-6 Revision May, 2018
 I/O Signal Connector (CN1)
Delta Part Number: ASDBCNDS0044
Delta Part Number: ASD-CNDS0015
 Communication Cable between Servo Drive and Computer
Delta Part Number: ASD-CNUS0A08
Title Part No.: ASD-CNUS0A08
Cable L
3000 ± 100 mm
118 ±4 inch
Connector
RJ connector RJ-45
USB connector A-type (USB V2.0)
L
80.1
22.5
1.8
21.2
Unit: mm
D-SUB 15 PIN PLUG
