Chapter 5 Parameters and Functions
5- 3
_5
12 40019
Transformer
quantities
0: 3CT3PT
1: 3CT2PT
2: 3CT0PT
3: 2CT3PT
4: 2CT2PT
5: 2CT0PT
6: 1CT3PT
7：1CT2PT
8：1CT0PT
word 2 R/W
13 40020 Reserved
14 40021 Timeout 1 – 99 word Second 2 R/W
15 40022 Reserved
16 40023 Baud Rate
0: 9600
1: 19200
2: 38400
word bps 2 R/W
17 40024 Communication mode 1: RTU word 2 R/W
18 40025 Data bit 0: 8 word bit 2 R/W
19 40026 Stop bit
0: None
1: Even
2: Odd
word 2 R/W
1A 40027 Stop bit 0: 1 word bit 2 R/W
1B 40028 Modbus address 0 – 254 word 2 R/W
1C 40029 Reset
0: None
word 2 W 1: Reset to factory default
2: Reset energy value
1. Meter Parameters: 0100 – 01FF
100 40257
Phase A voltage 0.000 – 99999.999 float V 4 R
101 40258
102 40259
Phase B voltage 0.000 – 99999.999 float V 4 R
103 40260
104 40261
Phase C voltage 0.000 – 99999.999 float V 4 R
105 40262
