Delta Din-rail Power Meter DPM- D510 User Manual
5- 2
_5
5.1 Overview of Parameters
Modbus
Address
Item Range
Data
Type
Unit
Data
Size
(byte)
Read (R) /
Write (W)
Hex
Modicom
Format
0. System Parameters: 0001 – 00FF
5 40006 Meter Constant 3200 uint P/kWh 2 R
6 40007 Meter Model
0: None
19：DPM-510
word 2 R
7 40008
Total running time of
the meter
Day: 0–65535 uint Day 2 R
8 40009
Hour: 00–23
Minute: 00–59
byte
Hour,
Minute
2 R
9 40010 Firmware version 0.00 – 9.99 uint 2 R
A 40011
Firmware release
date
Year: 00–99
Month: 1–12
byte
Year,
Month
2 R
B 40012 Date: 1–31 word Date 2 R
C 40013 Reserved
D 40014
Power system
configuration
0：3P4W
1：3P3W
2：1P2W
3：1P3W
word 2 R/W
E 40015 Primary CT (A) 1 – 9999 uint A 2 R/W
F 40016 Secondary CT (A)
0: 1A
1: 5A
word A 2 R/W
10 40017 Primary PT 1 – 9999 uint V 2 R/W
11 40018 Secondary PT 1 – 9999 uint V 2 R/W
