3 Mixed Analog Input/Output Module DVP06XA-E2
DVP-ES2 Module Manual
3-6
DVP06XA-E2
CR# Attrib. Register content
Description
#28 YES R/W Adjusted Offset value of CH1
#29 YES R/W Adjusted Offset value of CH2
#30 YES R/W Adjusted Offset value of CH3
#31 YES R/W Adjusted Offset value of CH4
Set the adjusted Offset value of Ch1 ~ Ch4. Default = K0
Definition of Offset at Ch1 ~ Ch4 in DVP06XA-E2:
The corresponding voltage (current) input value when the digital
output value = 0
#32 YES R/W Adjusted Offset value of CH5
#33 YES R/W Adjusted Offset value of CH6
Set the adjusted Offset value of Ch5 ~ Ch6. Default = K0
Definition of Offset at Ch5 ~ Ch6 in DVP06XA-E2:
The corresponding voltage (current) output value when the
digital input value = 0
#34 YES R/W Adjusted Gain value of CH1
#35 YES R/W Adjusted Gain value of CH2
#36 YES R/W Adjusted Gain value of CH3
#37 YES R/W Adjusted Gain value of CH4
Set the adjusted Gain value of CH1 ~ CH4. Default = K16,000
Definition of Gain at Ch1~Ch4 in DVP06XA-E2:
The corresponding voltage (current) input value when the digital
output value = 16,000
#38 YES R/W Adjusted Gain value of CH5
#39 YES R/W Adjusted Gain value of CH6
Set the adjusted Gain value of Ch5 ~ Ch6. Default = K16,000
Definition of Gain at Ch5 ~ Ch6 in DVP06XA-E2:
The corresponding voltage (current) output value when the
digital input value = 16,000
#40 YES R/W
Function: Set value changing
prohibited
Prohibit set value changing in CH1 ~ CH4
#41 NO R/W Function: Save all the set values Save all the set values, Default =H’0000
#42 NO R/W Function: Return to default setting Set all values to default setting, Default = H’0000
#43 NO R Error status
Register for storing all error status. See the table of error status for
more information.
#44 ~ #99 Reserved
#100 YES R/W
Function: Enable/Disable limit
detection
Enable/Disable the upper and lower bound detection function.
#101 NO R/W Upper and lower bound status Display the upper and lower bound value, Default =H’0000
#102 YES R/W Set value of CH1 upper bound
#103 YES R/W Set value of CH2 upper bound
#104 YES R/W Set value of CH3 upper bound
#105 YES R/W Set value of CH4 upper bound
#106 YES R/W Set value of CH5 upper bound
#107 YES R/W Set value of CH6 upper bound
Set value of CH1~CH6 upper bound. Default: K32,000
#108 YES R/W Set value of CH1 lower bound
#109 YES R/W Set value of CH2 lower bound
#110 YES R/W Set value of CH3 lower bound
#111 YES R/W Set value of CH4 lower bound
#112 YES R/W Set value of CH5 lower bound
#113 YES R/W Set value of CH6 lower bound
Set value of CH1~CH6 lower bound. Default: K-32,000
#114 YES R/W Output update time of CH5
#115 YES R/W Output update time of CH6
Set output update time of CH5 ~ CH6
#116 ~ #117 Reserved
#118 YES R/W
LV output mode setting of Ch5 ~
Ch6
Set the output mode of CH5~CH6 when the power is at LV (low
voltage) condition. Default=0
Symbols:
YES: When CR#41 is set to H’5678, the set value of CR will be saved. NO: Set value will not be saved
R: Able to read data by FROM instruction, W: Able to write data by using TO instructions
For voltage input Mode0/Mode2: 0.3125mV = 20V/64,000 = 10V/32,000.
For voltage input Mode1/Mode3: 0.15625mV
= 10V/64,000 = 5V/32,000
For current input Mode4/Mode5: 0.625A = 40mA/64,000 = 20mA/32,000
For current input Mode6: 0.5A = 16mA/32,000
For voltage output Mode0: 0.3125mV = 20V/64,000
For current output Mode1: 0.625A = 20mA/32,000
For current output Mode2: 0.5A = 16mA/32,000
