Delta DVP-ES2

4 Temperature Measurement Module DVP04PT-E2
4.7.1 Conversion Curve
1. Mode 0 (H’0000): PT100 mode °C (
°F) / Mode 2 (H’0002): PT1000 mode °C (°F)
+8,000
-1,800
-180
Digital output
Measured
temperature input
C
+800
C
+14,720
-2,920
+1,472
-292
F
Digital outpu
t
Measured
temperature input
F
Mode 0, 2 of CR#2~ CR#5 -180°C ~ 800°C (-1800~8000), -292°F ~ 1472°F (-2920~14720)
Offset (CR#34 ~ CR#37) Offset value
2. Mode 1 (H’0001): NI100 mode °C (°F) / Mode 3 (H’0003): NI1000 mode °C (°F)
+1,700
-800
+170
-80
C
Digital output
Measured
temperature input
C
+3,380
-1,120
+338
-112
F
Digital output
Measured
temperature input
F
Mode 1, 3 of CR#2~ CR#5 -80°C ~ 170°C (-800~1700) , -112°F ~ 338°F (-1120~3380)
Offset (CR#34 ~ CR#37) Offset value
3. Mode 4 (H’0004): 0~300 
3000
300Ω
Digital output
Measured input
impedance
0
Mode 4 of CR#2~ CR#5 0 ~ 300 (0~3000)
Offset (CR#34 ~ CR#37) Offset value
DVP-ES2 Module Manual
