Delta DVPSCM Series User Manual

Communication Module DVPSCM12/52-SL
DVP-PLC Operation Manual
2
 Environmental specifications
Item Specifications
Noise immunity
ESD (IEC 61131-2, IEC 61000-4-2): 8 kV Air Discharge
EFT (IEC 61131-2, IEC 61000-4-4): ±1 KV (Communication I/O)
CS (IEC 61131-2, IEC 6100-4-6): 0.15 ~ 80 MHz, 3 Vrms
RS (IEC 61131-2, IEC 61000-4-3): 80 ~ 100 MHz, 10 V/m, 1.4 ~ 2.0 GHz
Operating/Storage
temperature
Operation: 0 ~ 55°C (temperature); 50 ~ 95% (humidity); pollution degree 2
Storage: -25 ~ 70°C (temperature), 5 ~ 95% (humidity)
Shock/Vibration
resistance
International standard norms IEC61131-2, IEC68-2-6 (TEST Fc) / IEC61131-2 &
IEC 68-2-27 (TEST Ea)
Standard
 Electrical Specifications
Item Specifications
Supply voltage 24 V DC (supplied by the internal bus through the MPU)
Power consumption 1.5 W
Insulation voltage 2500 VDC
Weight Approximately 95 g
 BACnet Protocol Implementation Statement
 Introduction of the standard BACnet device
Model Introduction
DVPSCM52-SL BACnet Application Specific Controller (B-ASC)
 BIBBs which are supported
Model BIBBs BIBB name
DS-RP-B Data Sharing-ReadProperty-B
DS-WP-B Data Sharing-WriteProperty-B
DM-DDB-B Device Management-DynamicDeviceBinding-B
DM-DOB-B Device Management-DynamicObjectBinding-B
DM-DCC-B
Device
Management-DeviceCommunicationControl-B
DS-RPM-B Data Sharing-ReadPropertyMultiple-B
DVPSCM52-SL
DS-WPM-B Data Sharing-WritePropertyMultiple-B
 Objects which are supported
Model Object Creation Deletion
Analog value Not supported Not supported
Binary value Not supported Not supported
DVPSCM52-SL
Device Not supported Not supported
 Data link layer options
Model Data link Baud rates which are supported
DVPSCM52-SL MS/TP Slave 9600, 19200, 38400, 76800
 Character set which is supported
Model Character set
DVPSCM52-SL ANSI X3.4
