Delta Electronics Servo Press E-Series Installation and Maintenance Instructions
17
5.3 Details of Drive Power Distribution
5.3.1 0.4 kW~1 kW
0.4 kW ~ 1 kW
R
S
T
L
1C
L
2C
P1
P2
P3
D
C
U
V
W
External power
supply
(AC220V)
Motor power
(Power Cable)
Red
Write
Black
