Delta Electronics Servo Press E-Series Installation and Maintenance Instructions
7
3.1.3 AM-ESP-E002-XXXX / AM-ESP-E001-XXXX models
The fixed servo press is installed with a flange. The fastening ports are shown in the figure below.
Please use 4 general M8X1.25 hex screws (JIS strength 12.9, length 40) and apply the tightening
torque of 334 kgf-cm.
Caution: Please note that the equipment has to be closely attached to the locking and fastening
platform while fastening the servo press.
: Locking and fastening site
Suggested digging size

Delta E Series Specifications

General

Series	E Series
Type	Inverter
Frequency	50 Hz / 60 Hz
Protection Features	Over voltage, Over current, Short circuit, Over temperature
Dimensions	Varies by model
Weight	Varies by model
Storage Temperature	-40°C ~ +70°C
