Delta Electronics Servo Press E-Series Installation and Maintenance Instructions
5
3. Installation Setup
3.1 Fixed Way
3.1.1 AM-ESP-E050-XXXX/AM-ESP-E030-XXXX models
The fixed servo press is installed with a flange. The fastening ports are shown in the figure below.
Please use 8 general M12X1.75 hex screws (JIS strength is 12.9, length 60) and apply the tightening
torque of 1160 kgf-cm.
Caution: Please note that the equipment has to be closely attached to the locking and fastening
platform while fastening the servo press.
: Locking and fastening site
