Appendix A: Wiring
deltamotion.com 33
Manufacturer-Specific Wiring Labels and Colors
These diagrams provide only transducer manufacturer labels and
colors. Follow all wiring instructions on p.32
Balluff Micropulse BTL-5 with SSI output
Styles: Z, W, K, P
12-pin Axis
Connector
+ Clk
- Clk
+Data
-Data
+PwrCmn
Int/Clk+
Int/Clk-
Cmn
Ret/Dat+
Ret/Dat-
Case
+24 V
GND
Yellow
Pink
Gray
Green
Brown
Blue
MTS Temposonics with SSI output
Models: R, RP, RH
12-pin Axis
Connector
(+) Clock
(-) Clock
(+) Data
+PwrCmn
Int/Clk+
Int/Clk-
Cmn
Ret/Dat+
Ret/Dat-
Case
+24 Vdc, Customer Supplied
DC Ground
Yellow
Green
Pink
Gray
Red or Brn
White
(-) Data
