Delta RMC70 - Page 37

Appendix A: Wiring
deltamotion.com 35
12-pin Axis
Connector
Interrogate + Input
Interrogate - Input
Pulse + Output
Pulse - Output
+PwrCmn
Int/Clk+
Int/Clk-
Cmn
Ret/Dat+
Ret/Dat-
Case
Pwr+
GND
Yellow
Pink
Gray
Green
Brown
Blue
White
GND
White wire must remain unconnected.
12-pin Axis
Connector
(+) Interrogation or Start
(-) Interrogation or Start
(+) Gate or (+) Stop
+Pwr
Cmn
Int/Clk+
Int/Clk-
Cmn
Ret/Dat+
Ret/Dat-
Case
Customer Supplied Power (+Vdc)
DC Ground
Yellow
Green
Pink
Gray
Red or Brn
White
(-) Gate or (-) Stop
12-pin
Connector
(+) Interrogation
(-) Interrogation
(+) Gate Out, (+) Start/Stop
+Pwr
Cmn
Int/Clk+
Int/Clk-
Cmn
Ret/Dat+
Ret/Dat-
Case
+ VDC
DC Ground
Yellow
Green
Pink
Gray
Red
White
(-) Gate Out, (-) Start/Stop
or
or
or
or
or
or
Wh/Gy
Gy/Wh
Or/Wh
Wh/Or
Wh/Gr
Wh/Bu
- VDC
Frame
-Pwr
Blue
or Gr/Wh
Brown
or Bu/Wh
Manufacturer-Specific Wiring Labels and Colors
Follow all wiring instructions on p.34.
Balluff Micropulse BTL-5, digital RS-485 output
Styles: Z, W, K, E, P, R, AT
MTS Temposonics with digital output (Start/Stop or PWM)
Models: LH, LS, LD, LF, LPS, LPR, G, EP2, ER
MTS Temposonics II with DPM or RPM personality module
