MA Module Pin-out
Pin
Function
Flt In +
Fault Input
Flt In -
Fault Input
En Out +
Enable Output
En Out -
Enable Output
Ctrl Out
Control Output, ± 10 V 16-bit Analog
Cmn
Common
MDT Transducer
SSI Transducer
Int/Clk +
+ Interrogation
+ Clock
Int/Clk -
- Interrogation
- Clock
Ret/Dat +
+ Return
+ Data
Ret/Dat -
- Return
- Data
Cmn
Common
Case
RMC Chassis
Notes:
• The two Cmn pins are electrically the same.
• The user must supply power for the transducer.
