Appendix A: Wiring
deltamotion.com 39
AA Module Pin-out
Pin
Function
Flt In +
Fault Input
Flt In -
Fault Input
En Out +
Enable Output
En Out -
Enable Output
Ctrl Out
Control Output, ±10 V 16-bit Analog
Cmn
Common
Analog In +
Signal +
Jumper for
4-20 mA
Jumper for Current Transducer
Analog In -
Signal -
Cmn
Common
+10Vdc
Exciter
10 Volt source for potentiometer
Case
RMC Chassis
Notes:
• The two Cmn pins are electrically the same.
• The user must supply power for the transducer.
