No.
Multi-
function
Button
Description
Enter
Button
The button has multiple functions. Please refer to the following for detailed
information.
1. Enter the Main Menu
In the
Main Screen
(that shows the current operation mode), press
the button for 0.1 second and the UPS will enter the
Main Menu
(setup
mode). Please refer to
Chapter 9: LCD Display & Settings
.
2. Select and confirm the parameter
Press the button to choose the parameter you want to change and the
chosen parameter will flash. Then, press the
Scrolling up
or the
Scrolling down
button to change the parameter and press the enter
button again to confirm the change.
Scrolling
UP Button
The button has multiple functions. Please refer to the following for detailed
information.
1. Enter the Measurement Menu’s Output screen
In the
Main Screen
, press the button for 0.1 second and the UPS will
directly enter the
Measurement Menu’s Output
screen. For details
about the LCD items, see
Figure 9-1: Menu Tree
.
2. Scroll up/ Increase the setting value
The button can be used to navigate the setting items. Press the
button for 0.1 second to go to the previous setting item.
The button can also be used to set up the parameter. Press the
button for 0.1 second to increase the setting value. If the button
is pressed for more than 2 seconds, the setting value will
increase by its minimum adjustable unit every 0.2 second
automatically until the button is released or the setting value
reaches its maximum.
3. Reset LCD
Press the
Scrolling Up
and the
Scrolling Down
buttons together for
3 seconds to reset the LCD display.
Scrolling
Down Button
The button has multiple functions. Please refer to the following for detailed
information.
1. Enter the Measurement Menu
’
s Output screen
In the
Main Screen
, press the button for 0.1 second and the UPS will
directly enter the
Measurement Menu’s Output
screen. For details
about the LCD items, see
Figure 9-1: Menu Tree
.
To Next Page
